SCOPE概述

The purpose of this document is to clearly specifythenature of packaging required for use in delivery of Painted Components tothe NCR Manufacturing Facility.

本文清楚描述了 NCR 制造设备的喷涂零件在运送中的包装要求。

The documentapplies to all Painted Components, independent of substrate material.

本文适用于所有喷涂零件，表面不作处理的不包括。

RESPONSIBILITY职责

It is the responsibilityofthe NCR Supplier ManagementTeam (SLM) to ensure that all PaintedComponent Suppliers are aware of thisNCR Requirement, and to includeit within any operational or contractual arrangements created as part ofexisting or new supply lines.

NCR 供应商管理（SLM）小组负责确保所有喷涂零件供应商都清楚此 NCR要求，并且现有的产品或新的供应线都要有此要求。

It is the responsibility ofthePainted Component Supplier to ensurethat NCR's Painted Component Packaging requirements are adhered to during supply line operation.

喷涂零件供应商负责确保在在生产线操作过程中都要依附 NCR 的喷涂产品包装要求。

SCOPE概述

PAINTEDCOMPONENTDEFINITION 喷涂零件定义

Painted Components are defined as any components which have an external surface which has been finished using a paint product.

喷涂零件定义为：任何通过使用涂料进行表面处理使之具有外表面的零件

Paint may be Wetor Powder Coating type and can be partial, single or multiplelayer application.

涂料的类型可能是喷油或者粉末涂料，喷涂可以局部喷涂、单层喷涂或多次喷涂。

The specification appliesto paints of all colour, texture and gloss - Standard NCR Colours and any CustomColour type. (e.g. RAL, Pantone,Munsell or Bespoke NCR CustomerShades)

本规范可应用于所有颜色、材质和光泽的喷涂——标准 NCR 颜色和任何客户颜色。（如：色号、Pantone, Munsell、或预定 NCR 客户颜色）

PRIMARYPACKAGINGREQUIREMENT主要/基本包装要求

All Painted Components shall be delivered to theNCRFacility individually packed and ina manner that allows individual partsto be easily picked / separated fromthe lot.

所有运送到 NCR 的喷涂零件都要单独包装，并且包装方式应利于从批中取出单个产品。

-The Painted Components shall be packed individually by usingBubble Wrap (AirCap®CL 9.5mm x 4.2mm) or similarproduct which meets or exceeds the protective properties associated with theAirCap®material.

喷涂零件应使用气泡垫单独包装（AirCap® CL 9.5mm x 4.2mm )或者使用等同于甚至超过

AirCap 材料保护特性的相似产品包装。

- The Bubble Wrap shall completely encase the component and shall be held in place using a suitable adhesivetape, such as 'Tesa 4089 PV6', or similar.

气泡垫应完全包住零件，并应在适当的位置贴上用适当的胶带（如 Tesa 4089 PV6，或相似的产品）

- Application of the BubbleWrap and AdhesiveTape shall be such that separation of thecomponent fromthe packaging can only happen wherea definite separation activity is applied.

使用气泡垫时应该要求：只有当实施分开动作时，产品才能从包装带中分离。

- Where deliveries of Individually WrappedPainted Components involve use of a Pallet (or similar) to contain a quantity of components, the Pallet andPainted Components shall be Shrink Wrapped(or similar) to ensure components donot become separated during transport / delivery.

当使用货盘（或类似的工具）运送单独包装的喷涂零件以维护零件的数量时，货盘和喷涂零件应该紧密包装以确保零件在运送过程中不会分离。

- Where deliveries of Individually Wrapped Painted Componentsinvolve useof a Box or Carton tocontain a quantity of components, the Box or Carton shall be sealed by suitable method toensure components do not become separatedduring transport / delivery.

当使用盒子或纸板箱运送单独包装的喷涂零件时，盒子或纸板箱应采取适当的方式密封，以确保零件在运送过程中不会分离。

EXCEPTIONS例外

Exceptions to the above Primary Packaging Requirement can be agreedwith the NCR Gourdie SLMGroup.

与以上主要包装要求例外的情况可以与 NCR 的 SLM 小组商议。

Exceptions shall be grantedwhere the nature, geometry or supplyvolumes associated with the PaintedComponent are such that Individual Bubble Wrappingof components does not offer the bestvalue Supply Line Solution.

当喷涂产品的特性、几何或者供应量是单独气泡垫包装却不能提供最好的供应线解决方案

时，可以授权例外。

Exceptions may include, but are not limited to, the use of Returnable Packaging,alternative packing materials or useof Separators to avoid individual packaging.

例外的情况可能包括，但不仅限于，可回收包装的使用，另一种包装材料或使用隔离物以避免单独包装。

Exceptions shall be documentedusing appropriateNCR Deviation Paperwork (Ref SLM Deviation Process) which details the exception and the agreed packing method.

例外的情况应该使用适当的 NCR 不符合文件（参考 SLM 不符合程序），NCR 不符合程序包含了例外的情况和同意使用的包装方法。

IMPORTANT CRITERIA关键之处

Keydrivers that Painted ComponentSuppliers must be aware of regardingthe packaging and delivery of Painted Components are as follows -:

关于喷涂零件的包装和运送，喷涂零件供应商必须知道的关键之处如下：

• No Damageto be incurred during delivery ofcomponent to point of use.

• 在零件的运送过程中不能出现使用上的损坏

• Maintainconsistency of packaging during all deliveries.

• 在所有运送过程中保证包装的一致性

• Retaincopies of any Exception Documentation(Deviations)

• 保留所有例外（不符合）文件的副本
